The Fluidyne WF101-1199 is a robust and efficient orbital motor ideal for various industrial applications. Engineered with precision, this motor is designed to offer exceptional performance, reliability, and versatility.
Specifications
Model Number: WF101-1199
Displacement: 315 CC
Mount Type: 2-Bolt SAE A Flange
Shaft Type: 1″ Woodruff Keyed Shaft
Ports: 1/2″ NPTF Ports
Width: 1.65″ (42MM)
Case Drain: No Case Drain (7/16-20 O’Ring Plugged)
Special Features: Rotate Flange 90°
Features and Benefits
High displacement for superior torque and power output.
2-Bolt SAE A Flange design for versatile mounting options.
Woodruff keyed shaft enhances stability under load.
Compact width enables application in tighter spaces.
Made in USA under stringent quality standards.
Applications
Construction machinery
Agricultural equipment
Material handling systems
Hydraulic power units
Mobile hydraulic applications
Quality and Certification
The Fluidyne WF101-1199 orbital motor is constructed with high-quality materials to ensure durability and long service life. It adheres to industry-quality standards and is manufactured with precision engineering techniques.
For technical support and assistance, contact our product specialists at (800) 823-4937.
Danfoss, Charlynn WF101-1199 Quality Made Aftermarket Replacement with a 12-month manufacturer’s warranty.
